Easy to operate and durable QTJ4-35 concrete brick making machine

QTJ4-35 Block Making Machine concrete block making machine is Semi-automatic, it is easy to be installed and operated. Actually, it requires minimum four workers to operate this block making machine and other related machines, like mixer, belt conveyor. This machine uses strong table vibration to keep air away from the concrete, so it can make very strong concrete block/cement brick. This series of block making machines has good performance, high efficiency, low energy consumption, and meets national standards. Since its launch on the market, it has achieved good economic and social benefits and is an ideal equipment for producing high-quality blocks.

Product Detail

Product details page content section:

Product Description

QTJ4-35 is a semi-automatic concrete brick making machine that can produce hollow bricks, paving bricks, and interlocking bricks. Our machine can produce different types of bricks by changing molds. Equipped with conveyor belts can save production time and improve production efficiency. The machine’s mold bolts design is reasonable and very safe and wear-resistant. The control box of the machine uses a famous brand for electrical components，Very safe and reliable. Our machine's mold core uses very thick steel plates, which are very durable. Our feeding system is controlled by electricity, and the conveyor belt can be easily replaced, which can effectively increase the service life of the machine.

Specification

The QTJ4-35 semi-automatic concrete brick making machine can produce 4 standard hollow bricks of 200 * 200 * 400mm every 35 seconds, with a daily output of 3300 bricks. The overall size of the machine is 3800 * 1800 * 2200mm, with disassembly and assembly occupying 5 square meters. The overall weight of the machine is 1400 kilograms, the overall power of the machine is 9.55 kilowatts, and the voltage is 380 v. The size of the pallet equipped on this machine is 850 * 550 * 20mm.Machine excitation force up to 40kn, Faster brick forming speed, higher density, and better brick quality.

图片3.png 图片4.png

Advantage

This machine is a semi-automatic machine developed by our company based on the previous small and medium-sized block forming machines，Reasonable design, compact structure, achieving directional vibration, variable frequency braking, greatly reducing labor intensity. A machine equipped with different molds can produce various hollow and solid cut blocks, very cost-effective. Our company has 43 patented technologies ， use new technologies to produce machines, ensuring their reliability and durability. Our company has established branches in multiple countries in Africa, including Tanzania, Ethiopia, Nigeria, Cote d'Ivoire, Burkina Faso , The company's products have been exported to over 150 countries cumulatively，The product quality is absolutely guaranteed and highly favored by customers. Shandong Shunya Machinery Co., Ltd. is willing to cooperate with every domestic and foreign company to achieve common prosperity.
